CV10/S1 - S2 Check Valves

CV10/S1 - S2 Check Valves

CV10/S1 - S2 Check Valves

Check valves are commonly used armatures that can be applied for liquid, gaseous and steam applications. They increase the process safety and can be used instead of complicated armatures. Because of short installation time and installation distance, small dimensions; Ayvaz disco check valve appears to be advantageous.

Check valves provide the flows just one way. When liquid flows through to flowing direction, check valves open and let it pass. But liquid tries to flow opposite direction of flowing, check valves close and prevent passing.

Material Structure:
Body: AISI 304 investment casting (ÇV10/S1 Body AISI 316 investment casting ÇV10/S2)
Inner parts: AISI 304 stainless steel (ÇV10/S1)
AISI 316L stainless steel (ÇV10/S2)

Connection:
Wafer type

Nominal Diameter:
DN15 (1/2”) - DN100 (4”)

Working Pressure:
Up to 40 bars

Working Temperature:
-10ºC to 300ºC

Typical Applications:
Iron and steel industry
Heating air-conditioning pipe lines
Mineral, oil industry
Wood working, pulp and paper industry
Textile industry
Water and condensate lines
Nautical industry


Product Brochure

Click here to download the brochure of CV10/S1 - S2 Check Valves

Download Brochure (PDF)
